Auto I-Lock structure

What is Auto I-Lock structure?

IRISO' FPC/FFC connector "Auto I-Lock structure TM" is a connector with a structure that automatically locks when the FPC/FFC card is inserted. It eliminates the need to open and close slider cover or covers, and the structure locks the FPC/FFC card as soon as it is inserted, making it less likely to be inserted at an angle or incompletely Mating, improving work efficiency. Since it ensures reliable Mating, robot assembly is possible even when using FPC/FFC cards.

Benefits of using Auto I-Lock structure

Various problems can be solved by using Auto I-Lock structure.

  • Prevents imperfect Mating, reduces inspection processes, and improves productivity.
  • The unique terminal structure enables high-speed transmission of digital signals.
  • A GND terminal is provided to support noise suppression when using a shielded FFC.
  • Robot assembly is possible by automatically locking. Contribute to automation.

Auto I-Lock structure introduction video

Related article

Auto I-Lock structure Product Lineup

11600S series

Connector for 0.5mm pitch NON-ZIF RA type FFC compatible with shielded FFC that enables high speed transmission of digital signals. Shielded for anti-EMC measures. Optimized contact structure supports transmission ranges of over 20Gbps by selecting FFC (representative reference value defined by the company) Impedance matching: differential 100Ω. Auto I-Lock structure is hard to pull out but easy to remove. Adopts a pull-out prevention structure that locks as soon as the FFC card is inserted. In addition, it will contribute to the customer's Assembly automation as a Robot Friendly IRISO robot connector product.


11501S series

A 0.5mm pitch NON-ZIF RA type FFC connector that is compatible with shielded FFCs that enable high-speed digital signal transmission. Shielded for EMC protection. Optimized contact structure supports transmission speeds of over 20.0Gbps by selecting the FFC (representative reference value defined by the company). Impedance matching: differential 100Ω. Auto I-Lock structure is hard to pull out but easy to remove. Adopts a pull-out prevention structure that locks as soon as the FFC card is inserted. In addition, it will contribute to the customer's Assembly automation as a product compatible with IRISO Robot Friendly connectors.


11503S series

Connector for 0.5mm pitch NON-ZIF RA type FFC compatible with shielded FFC that enables high speed transmission of digital signals. Shielded for anti-EMC measures. Optimized contact structure supports transmission ranges of over 20Gbps by selecting FFC (representative reference value defined by the company). Impedance matching: Differential 100Ω. Auto I-Lock structure TM structure that is hard to pull out but easy to remove. Adopts a pull-out prevention structure that locks at the same time as the FFC card is inserted. Comes with a confirmation window that allows visual inspection of complete insertion of FFC. In addition, it will contribute to the customer's Assembly automation as a product compatible with IRISO Robot Friendly connectors.
