The Future Can Be Created ~The Story Behind the Development of Floating BtoB Connector~
Episode 2: "Breaking the Wall of 1mm"
Products
Floating Connector
10122 series
This 11.0mm pitch, Floating structure type Stacking connection (ST/ST) Board to Board Connector connector combines IRISO unique Floating structure technology with high current capability. The Floating (Floating structure) structure Floating of 1.0mm in the X direction and 0.5mm in the Y direction. The effective Mating in the Z direction is 0.5mm. It can handle a large current of 30A (600V, pollution level 2), contributing to improved workability when connecting high currents in multiple locations.
9851 series
1.0mm pitch, Floating structure type Stacking connection (ST/ST) Board to Board Connector connector. Floating (Floating structure) structure allows for an effective Mating of 0.5mm in the XY axis direction and 0.4mm in the Z direction. (Floating range varies depending on the combination.) Various board-to-board dimensions can be accommodated by the Mating connector.
10109 series
A 0.635mm pitch, Floating structure type Stacking connection (ST/ST) Board to Board Connector connector enabling high-speed transmission of digital signals. Floating (Floating structure) structure allows for 0.5mm Floating in the XY axis directions. It has an effective Mating length of 0.5mm in the Z direction. Supports high-speed transmission of 3.0Gbps (representative reference value according to our company's definition). Impedance matching: differential 100Ω. Features two-point contacts to accommodate various Mating heights and ensure reliable removal of foreign objects even in tough environments.
9827 series
A 0.8mm pitch, Floating structure type Stacking connection (ST/ST) Board to Board Connector connector enabling high-speed transmission of digital signals. Floating (Floating structure) structure allows for 0.5mm Floating in the XY axis direction. The effective Mating in the Z direction is 0.5mm. Supports high-speed transmission of 5.0Gbps (representative reference value according to our company's definition). Impedance matching: differential 100Ω.
9828 series
0.8mm pitch, Floating structure type Board to Board Connector connector. Floating (Floating structure) structure allows 0.5 mm Floating in the XYZ directions. Realizes space saving.
10106 series
0.5mm pitch, Floating structure type Stacking connection (ST/ST) Board to Board Connector connector for high-speed transmission of digital signals. Floating (Floating structure) structure with 0.5mm X Y direction to 0.5mm Floating effective Mating length in Z direction. 1.0Gbps (typical reference value based on in-house definition) for high-speed transmission. Impedance matching: 100 Ω differential. Mating Height 20.0 mm, 25.0 mm, and 30.0 mm Stacking connection of high profile are supported. 2-point contact for reliable foreign object removal even in tough environments.
10112 series
0.5mm pitch, Floating structure type Board to Board Connector connector that enables high-speed transmission of digital signals. Floating (Floating structure) structure allows 0.5 mm Floating in the XYZ directions. Compatible with V-by-One HS. Supports high-speed transmission. Impedance matching: 100Ω.
10126 series
0.4mm pitch Stacking connection (ST/ST) Board to Board Connector connector that enables high-speed transmission of digital signals. Supports high-speed transmission despite low profile, space-saving design Supports high-speed transmission of 12.0 Gbps (representative reference value defined by our company). Impedance Matching: Differential 100Ω.
